CMA Hand Winches
The GS series has slightly different appearances over the load ratings as seen in the pictures above.
About CMA Hand Winches
The CMA Series is a console mounted, chain transmission hand winch for pulling. All aluminum parts and enclosed chain drive makes it the ideal winch for harsh environments. Its automatic braking ensures safety and reliability, making the CMA series a dependable and corrosion resistant hand winch.
Specifications
Application:
Pulling
Material:
Aluminum
Working Load Limit:
440 - 1760 lbs
rope size:
3/16" - 5/16"
Drive:
Chain Drive
Brakes:
Spring Applied
Coating:
Uncoated / Painted
Mounting
Console
Advantages of CMA Hand Winch
Reliable Safety
The CMA Series utilizes spring applied brake to securely hold the load in any position.
High Versatility
Console mounting and 2 speed operation makes the CMA perfect for a wide range of applications.
High Strength to Weight Design
Constructed from aluminum castings and side frames, the CMA offers an ideal blend of strength and lightweight design.
Corrosion Protection
All CMA winch parts are aluminum to ensure the utmost corrosion protection for harsh environments.
Diagram of a CMA Hand Winch
Product Table
Simply add any item to your cart and complete the Request for Quote (RFQ) form. A member of our sales engineering team will respond promptly with pricing and availability.
Scroll Sideways on Your Mobile Device to View Product Data and the RFQ Button.
Product Tables Are Easier To See on Desktop Computers.
Model | Type | WLL (LBS) | Rope Diameter (IN) | Rope Storage (FT) | Base Length (IN) | Base Width (IN) | Overall Height (IN) | Bolt Patt Length (IN) | Bolt Patt Width (IN) | MT Bolt Diameter (IN) | Drum Diameter (IN) | Drum Width (IN) | RFQ CART |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
CMA440 | Aluminum | 440 | 3/16 | 131 | 7.56 | 6.3 | 6.5 | 6 | 5.31 | 5/16 | 1.97 | 4.72 | |
CMA1100 | Aluminum | 1100 | 1/4 | 164 | 13 | 8.66 | 10.51 | 3.94 | 4.92 | 3/8 | 2.36 | 4.72 | |
CMA1760 | Aluminum | 1760 | 5/16 | 256 | 13.23 | 12.83 | 12.87 | 7.09 | 9.84 | 1/2 | 2.76 | 7.87 |
Disclaimer: Due to our policy of continuing development, all specifications are subject to change without notice. Users of these products are responsible for ensuring their suitability for the application in which they are being used.
